High Efficiency Canned Vegetable Production Line For Cucumber

Place of Origin	Shanghai, China
Brand Name	Leadworld

Product Details

Condition:

New

Year:

OEM

Dimension(L*W*H):

5000*1000*2500

Weight:

5000 KG

Automatic Grade:

Automatic

Voltage:

380V

Power:

2.75KW

Machinery Capacity:

OEM

Key Machines:

Food Sterilizer, Fruit & Vegetable Peeling Machine, Pasteurizer, Emulsifier, Fryer, Mixer, Heat Exchanger, Cleaning Machine, Bottle Washer, Conveyor Line, Filling Machine

Product Type:

Ice Cream, Grain Products, Flour, SEAFOOD, CANDY, Vegetables, Chocolate, Fruit

Product Name:

Canned Food Cucumber Production Line

Grade:

Food Grade

Material:

Stainless Steel

Automatic Grade:

Full Automatic

Appication:

Food Canned Food

Cans Side:

Customized

Suitable Container:

Cans,bottles, Bags

Function:

High Speed And Fully Automatic

Capicity:

0.5-5 Ton Per Hour

Port:

Shanghai

High Light:

Cucumber Canned Production Line

Canned Vegetable Production Line 380V

Payment & Shipping Terms

Price

Negotiable

Packaging Details

Standard export package

Supply Ability

10 Unit/Units per Month

Product Description

Specification

Name	Technical parameter
Z type elevator	Equipment material: food grade stainless steel Material lifting
Shaker	Vibration and impurity removal before soaking and cleaning of raw materials
Cucumber soaking washing machine	Equipment material: food grade stainless steel Equipment size: 1500*6000mm Soak, Bubble, Lift
Manual selecting platform	Manual selecting
Continuous pre-cooker	Equipment material: food grade stainless steel Equipment size: 1500*8000mm Cucumbers are greened, temperature controlled
Continuous cooler	Equipment material: food grade stainless steel Equipment size: 1500*5000mm Rapid cooling after pre-cooking to maintain product appearance
Z type elevator	Equipment material: food grade stainless steel Material lifting
Vibration filling machine	Filling range: 330-900g/bottle Filling speed: 80-120 bottles/min (the capacity of the machine will vary according to the size of the cucumber and the size of the bottle) Manual feeding is required after filling Equipment material: food grade stainless steel Feed height: 1760mm
Automatic soup adding machine	Equipment material: food grade stainless steel soup added
Capping machine	Cap, screw cap, 5000-6000 bottles/hour Power: 2.04kw Steam demand: more than 180kg/h Dimensions: 345010402150mm
Bottles washing machine	Dimensions: 420015001800 Power: 5.35kw Capacity: 120 bottles/min Applicable bottle diameter: 40-180mm Suitable bottle height: 60-300mm Rinse method: two-stage cleaning (unlimited bottle type
Pasteurizer	Fully automatic control Equipment material: 304 stainless steel for the whole machine Automatic temperature control system Equipment size: effective width 2000mm/length 25000mm Insulation on three sides
Air knife blowing water	Used to blow-dry the water on the surface of the jar
Bottles palletizer	Standard machine (universal) Tray size: 1m*1.2m Jar shape: Universal glass bottle Production speed: 1-1.5 layers/minute Equipment size: length 6600mm width: 2300mm Equipment power: 7.5kw Air source consumption: 0.6MPa
